Name: Granite Stone Crusher HSI Mining Crushing Machine For Construction Gravel Plant
Brand: Hunan Yuantong Heavy Industry Co., Ltd.
SKU: PW3608
Availability: InStock

Home > Products > Sand Making Machine >

Granite Stone Crusher HSI Mining Crushing Machine For Construction Gravel Plant

HSI Mining Crushing Machine

HSI Granite Stone Crusher

Construction Plant Granite Stone Crusher

Place of Origin:

China

Brand Name:

Yuantong

Certification:

ISO

Model Number:

PW3608

Chat Now

Request A Quote

Product Details

Product Name:

Stone Crusher HSI Mining Crushing Machine

Warranty:

12 Months

Installation Method:

Stationary

Power Source:

Electricity

Application:

Construction Gravel Plant

Color:

Customizable

Capacity:

Varies Depending On Plant Size

Control System:

Automated

Highlight:

HSI Mining Crushing Machine

HSI Granite Stone Crusher

Construction Plant Granite Stone Crusher

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiable

Packaging Details

Small items: wooden box; Large device: container

Delivery Time

1-8 Weeks

Payment Terms

L/C,T/T

Supply Ability

200 sets/year

Granite Stone Crusher HSI Mining Crushing Machine For Construction Gravel Plant

Chat Now

Movable M Sand Crusher Machine For Temporary Construction Site Aggregate Supply

Chat Now

Pebble Crusher Movable Horizontal Shaft Impactor Crusher For Gravel Processing Plant

Chat Now

800kw Calcite To M-Sand Horizontal Shaft Impact Crusher For Road Base Gravel Production

Chat Now

86--18175766687

mo@hnytgs.com

Chat Now

Product Description

Granite Stone Crusher HSI Mining Crushing Machine

This Horizontal Shaft Impactor Crusher is engineered for construction gravel plants, delivering high-performance crushing capabilities for granite processing with exceptional efficiency and reliability.

Key Specifications

Product Name	Capacity	Power	Input Material	Output Function	End Users
Horizontal Shaft Impactor Crusher	120 t/h	400kw	Granite	Manufactured Sand (m-sand machine-made sand)	Construction sand and gravel processing plants

Primary Advantage

No investment required in primary crushing equipment - this system operates independently without additional infrastructure.

Market Opportunities

The construction industry's growing demand for manufactured sand (m-sand) is driven by environmental concerns and resource conservation. Government restrictions on river sand usage and the recycling of crusher byproducts are accelerating market growth for sustainable sand alternatives.

Two types of m-sand are available: coarse sand for concrete applications and fine sand for plastering. Advanced technology ensures high-quality materials for both segments.

Performance Features

Improved Grinding Efficiency & Reduced Energy Consumption

Better Particle Size Distribution & Quality

Lower Equipment Wear and Maintenance Costs

Enhanced Automation and Smart Manufacturing

Environmental and Green Benefits

Technical Parameters

Model	Max. Feed Size (mm)	Capacity (t/h)	Product Size (mm)	Output (t/h)	Motor Power (kw)	Dimensions (mm)
PW2006	≤70	40-50	0-5mm	25-30	90	360x150x207
PW2006	≤70	40-50	5-31.5mm	10-15	90	360x150x207
PW2008	≤80	60-80	0-5mm	40-55	160	362x191x210
PW2008	≤80	60-80	5-31.5mm	15-20	160	362x191x210
PW3008	≤90	90-110	0-5mm	55-65	250	385x242x255
PW3008	≤90	90-110	5-31.5mm	20-30	250	385x242x255
PW3308	≤100	120-140	0-5mm	70-90	315	432x296x266
PW3308	≤100	120-140	5-31.5mm	30-40	315	432x296x266
PW3608	≤100	160-200	0-5mm	110-130	400	518x318x312
PW3608	≤100	160-200	5-31.5mm	30-40	400	518x318x312
PW4010	≤100	300-400	0-5mm	200-250	2x315(400)	704x418x370
PW4010	≤100	300-400	5-31.5mm	60-80	2x315(400)	704x418x370

Packaging and Shipping

The impact crusher is securely packed in wooden crates to ensure transportation safety
All necessary parts and accessories are included in the package
Shipping via reliable and efficient service providers
Cost calculated based on destination and package weight
Delivery times vary depending on customer location
