Electricity Powered Aggregate Cone Crushers - High Performance Crush Force
Mobile Crushing Systems for Conical Crusher Machinery
High-strength cone crushers engineered with robust construction and enhanced crushing capabilities to handle tough materials and high-stress applications. These crushers are built to withstand extreme loads while delivering efficient crushing performance in challenging operating conditions across mining, metallurgy, construction, and related industries.
Product Features
- Product Name: Cone Crusher Machine
- Capacity: Varies by plant size requirements
- Application: Mines and Quarries
- Control System: Fully Automated
- Installation Method: Mobile crushing systems available
- Power Source: Electricity Powered
The Cone Crusher Machine, also known as Cone Stone Crusher or Cone Crushing Machinery, is designed for mines and quarries to process a wide range of materials. With automated control systems and mobile crushing options, it provides efficient and reliable performance for any crushing operation.
Technical Specifications
| Model |
Max. Feed Size (mm) |
Discharging Mouth (mm) |
Processing Power (t/h) |
Installed Power (kw) |
Overall Dimensions (cm) |
Weight (t) |
| PYH50 | 400 | 30-70 | 80-150 | 45-75 | 386x215x248 | 21 |
| PYH100 | 500 | 30-70 | 120-260 | 90-132 | 398x273x275 | 33 |
| PYH200 | 600 | 30-70 | 220-360 | 160-200 | 455x328x320 | 55 |
| PYH300 | 700 | 30-70 | 320-480 | 220-315 | 523x378x380 | 93 |
| PYH400 | 800 | 30-70 | 430-600 | 355-450 | 610x419x420 | 128 |
| PYH500 | 900 | 30-80 | 530-700 | 500-630 | 680x473x482 | 172 |
Applications
Widely applicable in metal and non-metal mines, cement production, sand and gravel aggregates, metallurgy, and related industries. With superior crushing ratios, these machines handle coarse, medium, and fine crushing of various ores, rocks, iron alloys, smelting slag, and other brittle materials with compressive strength up to 300MPa.
The Cone Crusher Machine features automated control systems and includes a 12-month warranty. Mobile crushing systems are available for flexible installation. Processing capacity varies according to plant size requirements.
Designed specifically for mines and quarries, these crushers efficiently process medium-hard to hard rock materials including granite, basalt, and limestone. Suitable for materials with compressive strength less than 350 MPa.
Support & Services
Our comprehensive technical support ensures optimal performance and maximum uptime:
- Professional installation and commissioning services
- Comprehensive maintenance and repair services
- Regular inspections and performance evaluations
- Technical training for operational staff
- 24/7 technical support via phone and email
Our experienced technicians and engineers provide high-quality support to keep your Cone Crusher Machine operating smoothly and efficiently.
Frequently Asked Questions
1. What type of stone needs to be crushed? Soft rock or hard rock?
2. What is the required output capacity? 100t/h? 300t/h?
3. What is the maximum feed size? 70 cm? 50 cm?
4. How many size specifications are needed for the final product?
Packaging & Shipping
Product Packaging
Each cone crusher is securely packaged in reinforced wooden crates with metal banding and internal foam cushioning to prevent damage during transit.
Shipping
Products are shipped via reliable courier services. Shipping fees vary by destination and product weight. Estimated delivery times are provided upon order confirmation.
