Product Description

High Capacity Cone Crusher Machine Mobile Crushing Systems Intelligent Control

High Capacity Mobile Crushing Systems Cone Crusher Machine for Mines and Quarries

Our company specializes in advanced international ore crushing technology and has independently developed this innovative crushing equipment for breaking hard rocks in mines and quarries. This powerful cone crusher overcomes the limitations of traditional jaw crushers and gyratory crushers, which often feature low crushing ratios, require multiple equipment setups, occupy excessive space, and incur high investment and operational costs.

Machine Selection Guide

• What type of stone needs to be crushed? Soft rock or hard rock?

• What is the required output capacity? 100t/h? 300t/h?

• What is the maximum feed size? 70 cm? 50 cm?

• How many size specifications are needed for the final product?

Key Features

High crushing ratio with feed particle sizes up to 400-900mm and product rate below 30mm reaching 60%
Combined one-stage and two-stage crushing in single machine, extended wear part life, 40% electricity savings, excellent particle shape
Intelligent control system with touchscreen adjustment of discharge port, iron block protection, overload protection, anti-blockage design, high automation, one-key start, safe and reliable operation
Low noise, minimal vibration, environmentally friendly operation, ideal for mobile crushing systems

Technical Specifications

Model	Max Feed Size (mm)	Discharge Range (mm)	Processing Capacity (t/h)	Installed Power (kw)	Dimensions (cm)	Weight (t)
PYH50	400	30-70	80-150	45-75	386x215x248	21
PYH100	500	30-70	120-260	90-132	398x273x275	33
PYH200	600	30-70	220-360	160-200	455x328x320	55
PYH300	700	30-70	320-480	220-315	523x378x380	93
PYH400	800	30-70	430-600	355-450	610x419x420	128
PYH500	900	30-80	530-700	500-630	680x473x482	172

This equipment is also known as Cone Stone Crusher or Conical Crusher Machinery.

Applications

This versatile cone crusher is widely used in mines and quarries for rock and mineral comminution. It finds applications across multiple industries including metal and non-metal mining, cement production, sand and gravel aggregates, metallurgy, and more. With its superior crushing ratio, it handles coarse, medium, and fine crushing of various ores, rocks, iron alloys, smelting slag, and other brittle materials with compressive strength up to 300MPa.

Suitable Materials

Hard and medium-hard ores
Rocks and minerals
Aggregates and construction materials
Various types of stones
Industrial materials

Technical Support & Services

24/7 technical support
On-site installation and commissioning
Operator and maintenance personnel training
Regular maintenance and inspection services
Warranty and post-warranty services
Supply of genuine spare parts and wear parts
