Name: High Strength Standard Cone Crusher Primary Gyratory Crusher In Mines And Quarries
Brand: Hunan Yuantong Heavy Industry Co., Ltd.
SKU: PYH500
Availability: InStock

Home > Products > Cone Crusher Machine >

High Strength Standard Cone Crusher Primary Gyratory Crusher In Mines And Quarries

High Strength Standard Cone Crusher

Mines And Quarries Standard Cone Crusher

High Strength Primary Gyratory Crusher

Place of Origin:

China

Brand Name:

Yuantong

Certification:

ISO

Model Number:

PYH500

Chat Now

Request A Quote

Product Details

Product Name:

Impact Crusher Machine

Capacity:

Varies Depending On Plant Size

Warranty:

12 Months

Control System:

Automated

Installation Method:

Mobile Crushing Systems Available

Color:

Customizable

Application:

Mines And Quarries

Power Source:

Electricity

Highlight:

High Strength Standard Cone Crusher

Mines And Quarries Standard Cone Crusher

High Strength Primary Gyratory Crusher

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiable

Packaging Details

Small items: wooden box; Large device: container

Delivery Time

1-8 Weeks

Payment Terms

L/C, T/T

Supply Ability

200 sets/year

High Power Cone Rock Crusher Stone Crushing Equipment Electricity Powered

Chat Now

Customizable Automated Mining Cone Crusher Varies Depending On Plant Size

Chat Now

530-700t/H Horizontal Cone Crusher Machine Designed For Primary And Secondary Crushing

Chat Now

High Capacity Cone Crusher Machine Mobile Crushing Systems Intelligent Control

Chat Now

86--18175766687

mo@hnytgs.com

Chat Now

Product Description

PYH500 High Strength Crushing Solution Cone Crusher Machine

Our company specializes in advanced international ore crushing technology and has independently developed this innovative crushing equipment for breaking hard rocks in mines and quarries. This powerful cone crusher overcomes the limitations of traditional jaw crushers and gyratory crushers, delivering superior performance in both open-pit and underground applications.

Application Scope

Widely applicable in metal and non-metal mines, cement production, sand and gravel aggregates, metallurgy, and related industries. With exceptional crushing ratio capabilities, it handles coarse, medium, and fine crushing of various ores, rocks, iron alloys, smelting slag, and other brittle materials with compressive strength up to 300MPa.

Key Features

High crushing ratio with feed particle sizes up to 400-900mm, achieving 60% product rate below 30mm
Combined one-stage and two-stage crushing in single machine, extended wear part lifespan, 40% electricity savings, superior particle shape
Intelligent control system with adjustable discharge port via touchscreen, iron block tolerance in crushing chamber, overload protection, anti-blockage design
Low noise and vibration operation, environmentally friendly, ideal for mobile crushing systems

Technical Specifications

Model	Max. Feed Size (mm)	Discharge Range (mm)	Processing Capacity (t/h)	Power (kw)	Dimensions (cm)	Weight (t)
PYH500	900	30-80	530-700	500-630	680x473x482	172

*Data based on materials with crushing hardness (Mohs hardness 3-7.5). Performance may vary depending on material characteristics, feed grading, moisture content, clay content, and bulk density.

Cone Crusher Structural Diagram

Working Principle

On-site Installation
