Name: 90kw - 400kw Limestone Crushing Equipment Horizontal Shaft Impactor Crusher
Brand: Hunan Yuantong Heavy Industry Co., Ltd.
SKU: PWS3608
Availability: InStock

Home > Products > Limestone Crusher Machine >

90kw - 400kw Limestone Crushing Equipment Horizontal Shaft Impactor Crusher

400kw Limestone Crushing Equipment

90kw Limestone Crushing Equipment

90kw Horizontal Shaft Impactor Crusher

Place of Origin:

China

Brand Name:

Yuantong

Certification:

ISO

Model Number:

PWS3608

Chat Now

Request A Quote

Product Details

Product Name:

Horizontal Shaft Impactor Crusher

Warranty:

12 Months

Installation Method:

Stationary

Power Source:

Electricity

Application:

Brick And Tile Manufacturing

Color:

Customizable

Capacity:

Varies Depending On Plant Size

Control System:

Automated

Highlight:

400kw Limestone Crushing Equipment

90kw Limestone Crushing Equipment

90kw Horizontal Shaft Impactor Crusher

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiable

Packaging Details

Small items: wooden box; Large device: container

Delivery Time

1-8 Weeks

Payment Terms

L/C,T/T

Supply Ability

200 sets/year

Automated Control Limestone Crushing Machine Cement Plant Crusher Stationary

Chat Now

Varied Capacity Horizontal Shaft Impact Crushing Machine Limestone Grinder Automated

Chat Now

High Speed Limestone Crusher Machine Impact Mill Rock Crusher Automated Control

Chat Now

30kw User Friendly Limestone Crushing Plant With Customizable Color

Chat Now

86--18175766687

mo@hnytgs.com

Chat Now

Product Description

20% Investment Saving Limestone Crushing Equipment Horizontal Shaft Impactor Crusher

This horizontal shaft impactor crusher is specifically designed for manufactured sand plants, offering significant investment savings while delivering high-performance limestone crushing capabilities.

Key Investment Benefits

Reduced Overall Investment: Features large crushing ratio and high production efficiency, minimizing the need for additional crushing equipment like cone crushers and impact crushers
Superior Particle Shape: Excellent output quality reduces investment in subsequent shaping equipment
Optimized Process Flow: Reduces equipment count while maintaining production scale and quality requirements
Proven Savings: In a Yunnan Province construction project, using our 150 t/h horizontal shaft impact crusher resulted in 20% overall equipment investment savings compared to alternative solutions

Technical Specifications

Model	Max. Feed Size (mm)	Capacity (t/h)	Product Size (mm)	Output (t/h)	Motor Power (kw)	Dimensions (mm)
PWS2006	≤80	80-100	0-5mm 5-31.5mm	20-60 30-70	90	295x246x318
PWS2008	≤100	120-160	0-5mm 5-31.5mm	30-90 60-120	160	331x284x361
PWS3008	≤100	180-220	0-5mm 5-31.5mm	40-125 85-170	250	461x296x396
PWS3308	≤120	240-280	0-5mm 5-31.5mm	50-160 100-210	315	465x326x416
PWS3608	≤120	320-400	0-5mm 5-31.5mm	80-220 160-300	400	475x360x446
PWS4010	≤150	800-1000	0-5mm 5-31.5mm	300-500 400-600	2x315(400)	704x418x510

Application Details

Product Name	Horizontal Shaft Impactor Crusher
Capacity	150 t/h
Power	400kw
Input Material	Limestone
Output Function	M sand production
End Users	Construction sand and gravel processing plants

No investment required in primary crushing equipment

Technical Support & Services

Installation and commissioning assistance
Regular maintenance and inspection
Troubleshooting and problem resolution
Spare parts and wear materials supply
Operational training and support
Upgrades and retrofits to improve performance and efficiency

Packaging & Shipping

Packaging: Equipment is securely packaged in plywood boxes to ensure safe transportation.
Shipping: Worldwide shipping available with various carriers. Shipping costs vary by destination and method - contact us for a quote.
