Name: Stationary Secondary Cone Crusher Powerful For Brick Tile Processing
Brand: Hunan Yuantong Heavy Industry Co., Ltd.
SKU: PYH500
Availability: InStock

Home > Products > Secondary Cone Crusher >

Stationary Secondary Cone Crusher Powerful For Brick Tile Processing

Tile Processing Secondary Cone Crusher

Secondary Cone Crusher Powerful

Brick Processing secondary impact crusher

Place of Origin:

China

Brand Name:

Yuantong

Certification:

ISO

Model Number:

PYH500

Chat Now

Request A Quote

Product Details

Application:

Brick And Tile Manufacturing

Product Name:

Secondary Cone Crusher

Color:

Customizable

Capacity:

Varies Depending On Plant Size

Control System:

Automated

Warranty:

12 Months

Power Source:

Electricity

Installation Method:

Stationary

Highlight:

Tile Processing Secondary Cone Crusher

Secondary Cone Crusher Powerful

Brick Processing secondary impact crusher

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiable

Packaging Details

Small items: wooden box; Large device: container

Delivery Time

1-8 Weeks

Payment Terms

L/C, T/T

Supply Ability

200 sets/year

High Productivity 18.5kw Secondary Cone Crusher With Varies Capacity

Chat Now

User Friendly Secondary Cone Crushing Machine Easy Installation

Chat Now

Customizable Rock Cone Crusher Machine With Automated Control System

Chat Now

Stationary Secondary Cone Crusher Powerful For Brick Tile Processing

Chat Now

86--18175766687

mo@hnytgs.com

Chat Now

Product Description

Stationary Secondary Cone Crusher for Brick and Tile Processing

Advanced Crushing Technology

Our stationary secondary cone crusher represents cutting-edge international ore crushing technology, specifically engineered for automated brick and tile manufacturing processes. This innovative equipment overcomes the limitations of traditional jaw crushers and gyratory crushers in both open-pit and underground applications.

Key Advantages

High crushing ratio with feed particle sizes up to 400-900mm
Product rate below 30mm reaching 60% efficiency
Combined one-stage and two-stage crushing in a single machine
Extended service life of vulnerable parts with 40% electricity savings
Superior particle shape output for quality manufacturing
Intelligent touchscreen control with adjustable discharge ports
Iron block protection and overload safety features
Anti-blockage design for full feeding operations
Automated one-key start system for reliable operation
Low noise and vibration for environmentally friendly performance

Technical Specifications

Model	Max Feed Size (mm)	Discharge Range (mm)	Processing Capacity (t/h)	Power (kw)	Dimensions (cm)	Weight (t)
PYH50	400	30-70	80-150	45-75	386x215x248	21
PYH100	500	30-70	120-260	90-132	398x273x275	33
PYH200	600	30-70	220-360	160-200	455x328x320	55
PYH300	700	30-70	320-480	220-315	523x378x380	93
PYH400	800	30-70	430-600	355-450	610x419x420	128
PYH500	900	30-80	530-700	500-630	680x473x482	172

* Data based on materials with crushing hardness (Mohs hardness 3-7.5). Performance may vary depending on material characteristics, feed grading, moisture content, clay content, and bulk density. All data for reference only.

Application Scope

This versatile cone crusher excels in multiple industrial applications including metal and non-metal mines, cement production, sand and gravel aggregates, and metallurgical processes. With exceptional crushing ratios, it handles coarse, medium, and fine crushing of various materials with compressive strength up to 300MPa.

Compatible Materials

Hard and medium-hard ores and minerals
Various rock types and geological formations
Construction aggregates and building materials
Industrial materials and processing byproducts
Iron alloys and smelting slag
Brittle materials for brick and tile manufacturing

Selection Guidance

For optimal equipment selection, consider your specific requirements:

Material type: Soft rock or hard rock?
Production output: Target capacity (100t/h, 300t/h, etc.)
Maximum feed size: 70cm, 50cm, or other dimensions?
Finished product specifications: Number of size grades required
